Features
- USA built, proprietary 18" driver with powerful motor strength and efficiency.
- Patented digital ICEpower® 725W amplifier with DSP control
- CNC precision cut cabinets that are finished in our industry exclusive satin black texture
- 17Hz-200Hz +/-3dB (7Hz-11Hz typical in-room extension)
CEA-2010 Ratings
- Ultra-low bass (20-31.5 Hz): 115.2dB
- Low bass (40-63Hz): 128.7dB
*Subtract 9dB for an equivalent RMS 2m ground plane measurement distance.
Power Sound Audio Product Comparison
Shipping
- Includes shipping to continental USA
- Package Information
- Shipment dimensions (D x W x H): 27" x 25" x 26"
- Shipment weight: 93lbs
- Carrier: FedEx
-
Driver
- Power Sound Audio proprietary 18” driver
- Extended and vented pole geometry
- Vented back plate to maximize air flow
- Extremely linear and dynamic motor system
- Epoxy reinforced cone neck/apex joint
- Concentric foam surround, treated for longevity
- Highly treated, rigid paper cone body
- Die-cast rigid aluminum frame
- Three inch diameter, four layer copper voice coil wound on a rigid multi-layer aluminum former with Kapton heat shielding
- Fatigue limiting designed, silver alloy lead wires
- Single poly cotton semi-progressive, high excursion spider
- Paper outer dust cap with acrylic coating
- Inner Mass Loading Cap that also strengthens the cone body
- Assembled in the USA
Amplifier Specifications
- ICEpower® audio technology
- Amplifier Power: 725 watts
- Inputs: Left and Right RCA inputs
- On, Auto, Off selector
- Gain control
- Time delay(phase) control
- Crossover control
- Room size control
- Custom DSP(digital signal processing) enables superior engineering refinement
- CE and FCC approved; EMC and safety pre-approved
- Fully integrated amplifier and power supply with mains-converter and auxiliary-converter
- Patented HCOM modulation and control techniques for unparalleled audio accuracy
- Sound optimized soft clipping
- Soft start power up with mute/de-mute.
- Thermal and over-current protection
- Standby converter with low standby power consumption (less than 1 watt)
- Universal mains operation (100-240 V, 50-60 Hz)
- Standby power consumption 170 mW @ 230 V
- ErP (1275/2008/EC) compliant
- Energy Star®v3.0 compliant
- 117 dBA dynamic range
- THD+N = 0.005 % @ 1 W (4 Ω, 1 kHz)
- THD+N = 0.0008 % @ 50 W (4 Ω, 100 Hz)
- CCIF IM distortion = 0.0003 %, 10 W, 4 Ω, 18.5 kHz / 1 kHz
- High output current limit of 30 A
Enclosure
- Sealed enclosure
- Front-firing driver with grill cover
- Super durable, black sand textured finish
- Precision machined CNC panels for perfect fit of all components
- Rigid MDF baffles
- Dimensions (D x W x H): 22" x 20" x 20.5" includes grill
- Weight: 79 lbs
- Made in the USA
Owner's Manual
S1800 Owner's Manual
-
FREQUENCY RESPONSE
* 2 meter ground plane (1/3 Octave smoothing)
LONG TERM OUTPUT COMPRESSION
-
Jim Wilson, Home Theater Shack Moderator/Reviewer, took a look at the S1800 home theater subwoofer. Click on the Home Theater Shack logo to read the full review."
"Whether it was the sound generated by thousands of hooves or the guttural snarls from the Morgul beasts, the S1800 resolved them all with exquisite detail. No part of the soundtrack washed away, regardless of how complex it was."
"The simple and thick rhythm of this song lends itself to something that would play well live, so it was that volume level I decided to try and replicate. While no single 18" subwoofers could effectively achieve that much impact in my living room, I still pushed the S1800 toward it nonetheless. In the end it did a remarkable job; Carmine's bass was abundant and silky smooth, which contributed mightily to the slick beat. This became one of those "have to listen again" tracks, so I did just that. "
