Unleash your home theater
Create the very best home theater experience with a powered subwoofer from Power Sound Audio. Energize your room with fast, dynamic bass and cinema quality sound.
-The ultra compact S1510 powered home audio subwoofer leads the pack with deeper extension, more thunderous output, and better overall sound quality. The S1510 subwoofer is the new standard for ultra compact sealed subwoofers.
-The S1510 subwoofer is powered by a 960W RMS (2100W PEAK) built-in amplifier with ICEpower® audio technology. A DSP based feature board includes the essential controls to properly integrate the subwoofer into your system.
-The MDF enclosure is heavily braced and assembled with rabbet joints for strong structural integrity. The enclosure is finished with a non-reflective and extremely durable textured material. The front-firing 15 inch subwoofer driver is covered with an acoustically transparent fabric grille. The amplifier is mounted on the rear baffle.
-The S1510 contains a 15 inch subwoofer driver, which is capable of moving massive amounts of air. The 1 inch surround and poly cotton semi-progressive, high excursion spider allow the cone to move more than 2 inches peak to peak. The cast aluminum frame is mounted to the extremely linear and dynamic motor system, which provides the power to drive the cone in a symmetrical motion.
| Design |
Sealed |
| Drivers |
15" High Excursion |
| Powered |
Yes |
| Amp |
960W RMS (2100W PEAK) |
| Enclosure |
CNC machined MDF |
| Frequency Response |
19Hz-200Hz +/-3dB |
| In-Room Extension |
7Hz-14Hz |
| Size (DxWxH) |
18" x 17" x 17.25" |
| Weight |
63 lbs |
Amp
ICEpower® audio technology
Amplifier Power: 960 watts
Inputs: Left and Right RCA
Inputs: Left and Right XLR
12V Trigger
On, Auto, Off selector
Gain control
Time delay(phase) control
Crossover control
Room size control
Custom DSP(digital signal processing) enables superior engineering refinement
CE and FCC approved; EMC and safety pre-approved
Fully integrated amplifier and power supply with mains-converter and auxiliary-converter
Patented HCOM modulation and control techniques for unparalleled audio accuracy
Sound optimized soft clipping
Soft start power up with mute/de-mute.
Thermal and over-current protection
Standby converter with low standby power consumption (less than 1 watt)
Universal mains operation (100-240 V, 50-60 Hz)
Standby power consumption 170 mW @ 230 V
ErP (1275/2008/EC) compliant
Energy Star®v3.0 compliant
117 dBA dynamic range
THD+N = 0.005 % @ 1 W (4 Ω, 1 kHz)
THD+N = 0.0008 % @ 50 W (4 Ω, 100 Hz)
CCIF IM distortion = 0.0003 %, 10 W, 4 Ω, 18.5 kHz / 1 kHz
High output current limit of 30 A
Assembled by Power Sound Audio
Cabinet
Sealed Enclosure
Front-firing driver
Acoustically transparent fabric grille cover
Super durable, black sand textured finish
Wood veneer options available
Precision machined CNC panels
Rigid MDF baffles
Heavily braced
Rear mounted amplifier
USA manufactured rubber feet
Dimensions (DxWxH): 18"x17"x17.25"
Weight: 63 lbs
Made in the USA
Woofer
Power Sound Audio proprietary 15” driver
Extended and vented pole geometry
Vented back plate to maximize air flow
Double stacked 80oz. ferrite magnets
Extremely linear and dynamic motor system
Epoxy reinforced cone neck/apex joint
Concentric foam surround, treated for longevity
Highly treated, Kevlar-reinforced rigid paper cone body
Die-cast, twelve spoke, rigid aluminum frame with under spider cooling vents
Three inch diameter, four layer copper voice coil wound on a rigid multi-layer aluminum former with Kapton heat shielding
Fatigue limiting designed, silver alloy lead wires
Single poly cotton semi-progressive, high excursion spider
Paper outer dust cap with acrylic coating
Assembled in the USA
S1510 Frequency Response
The frequency response graph shows how the subwoofer will sound for a given input frequency or tone. Accurate reproduction of the source material is achieved with a flat frequency response as shown in the graph.
S1510 Compression
The compression graph indicates how the output of the subwoofer changes as the input signal increases.
