Special Order Only - Contact Before Purchase
Unleash your home theater
Create the very best home theater experience with a powered subwoofer from Power Sound Audio. Energize your room with fast, dynamic bass and cinema quality sound.
-The EV18F-M powered home theater subwoofer is a perfect choice for the bass enthusiast. Designed to accurately reproduce source material at extremely high levels, the EV18F-M delivers concussive output during the most intense action movie, and accurate musical definition like you've never heard from a vented subwoofer.
-The EV18F-M subwoofer is powered by a 1920W RMS (4300W PEAK) built-in amplifier with ICEpower® audio technology. A DSP based feature board includes the essential controls to properly integrate the subwoofer into your system.
-MDF enclosure that is finished with a non-reflective matte covering. An acoustically transparent fabric grille covers the front-firing 18-inch subwoofer driver. The amplifier is mounted on the rear baffle.
-The EV18F-M contains a single 18-inch Ferrite woofer with a newly designed motor and suspension specific to Power Sound Audio's target goals.
Design | Vented |
---|---|
Drivers | 18" Ferrite High BL Woofer |
Powered | Yes |
Amp | 1920W RMS (4300W PEAK) |
Enclosure | CNC machined MDF |
Frequency Response | 16hz-150Hz Anechoic (+/-3dB) |
In-Room Extension | 12hz-15Hz |
Unboxed Size (DxWxH) | 22" x 20" x 24" with grille |
Boxed Size (DxWxH) | 26" x 24" x 30" |
Unboxed Weight | 125 lbs |
Boxed Weight | 141 lbs |
Included In The Box
-One EV18F-M powered subwoofer-Grille
-One owner's manual
-One 6' AC power cord
-Four furniture (carpet) sliders
Amp
-ICEpower® audio technology-Amplifier Power: 1920 watts
-Inputs: Left and Right RCA
-Inputs: Left and Right XLR12V Trigger
-On, Auto, Off selector
-Gain control
-Time delay(phase) control
-Crossover control
-Room size control
-Custom DSP(digital signal processing) enables superior engineering refinement
-CE and FCC approved; EMC and safety pre-approved
-Fully integrated amplifier and power supply with mains-converter and auxiliary-converter
-Patented HCOM modulation and control techniques for unparalleled audio accuracy
-Sound optimized soft clipping
-Soft start power up with mute/de-mute
-Thermal and over-current protection
-Standby converter with low standby power consumption (less than 1 watt) -Universal mains operation (100-240 V, 50-60 Hz)
-Standby power consumption 170 mW @ 230 VErP (1275/2008/EC) compliant
-Energy Star®v3.0 compliant
-117 dBA dynamic range
-THD+N = 0.005 % @ 1 W (4 Ω, 1 kHz)
-THD+N = 0.0008 % @ 50 W (4 Ω, 100 Hz)
-CCIF IM distortion = 0.0003 %, 10 W, 4 Ω, 18.5 kHz / 1 kHz
-High output current limit of 30 A
-Assembled by Power Sound Audio
Cabinet
-Vented/Ported Enclosure-Elaborate slot port design offers a unique blend of extension and laminar air flow
-Front-firing driver
-Acoustically transparent fabric grille cover
-Non-reflective matte black finish
-Rigid MDF baffles
-Heavily braced
-Rear mounted amplifier
-Dimensions (DxWxH): 22"x20"x24" includes grille
Woofer
-Country of origin: China-4800 W continuous program power capacity
-100mm (4 in.) four layer copper voice coil
-Large Ferrite magnet structure refined for sound quality and high motor force
-(BL)Double suspension spiders for improved control under high excursions
-Ventilated voice coil gap combined with extraordinarily high power capacity virtual eliminate thermal compression
-Low inductance motor to maximize sound quality
Performance coming soon!
