TV21 Ipal
TV21 Ipal
TV21 Ipal
TV21 Ipal
TV21 Ipal
TV21 Ipal

TV21 Ipal

Regular price$3,899.99
/

Quantity
EQ
Other Options in Similar Size

Unleash your home theater

Create the very best home theater experience with a powered subwoofer from Power Sound Audio. Energize your room with fast, dynamic bass and cinema quality sound.



-The TV21 Ipal has established itself as an industry unicorn. True 10-12hz extension, unparalleled sound quality thanks to the USA 4000W amplifier combined with the Italian 21 inch IPAL woofer, and a violent amount of mid and upper bass performance. All in a surprisingly small vented cabinet.

-The TV21 Ipal subwoofer is powered by a 4000W RMS (6000W PEAK) cabinet mounted amplifier. A DSP based feature board includes the essential controls to properly integrate the subwoofer into your system.

-The MDF enclosure is heavily braced and assembled with rabbet joints for strong structural integrity. The enclosure is finished with a non-reflective and extremely durable textured material. An acoustically transparent fabric grille covers the front-firing 21 inch subwoofer driver. The amplifier is mounted on the rear baffle.

-The TV21 Ipal contains a 21 inch Ipal neodymium motor woofer from B&C in Italy. With class leading thermal handing, motor strength, and inductance considerations you are assured of powerful and accurate bass reproduction.
Design Vented
Drivers 21" Italian IPAL Woofer
Powered Yes
Amp 4000W RMS (6000W PEAK)
Enclosure CNC machined MDF
Frequency Response 12hz-170hz Anechoic (+/-3dB)
In-Room Extension 8Hz-11Hz
Size (DxWxH) 27" x 24" x 27" with grille
Weight 165 lbs

Amp

  • Amplifier Power: 3800W RMS 6100W Peak
  • Amplifier Topology: Innovative post-filter feedback class-D topology, achieves ruler-flat frequency response, low distortion and very high damping across the whole audio band
  • Uses latest generation power MOSFET transistors and highly optimized output stage for up to 95% efficiency, allowing quiet fan-less operation up to unprecedented power levels
  • Full featured protection: DC, overload, low impedances, shorts, under/over-voltage, overheating, etc.
  • Includes gentle soft-start and long-term power limiter to reduce the chances of  tripping breakers
  • 120VAC (optional 120VAC-240VAC for an additional charge)
  • Unbalanced Inputs: Left and Right RCA
  • Balanced Input/Output: XLR input and XLR loop output.
  • On, Auto, Off selector
  • Gain control
  • Time delay(phase) control
  • Crossover control
  • Room size control
  • Custom DSP(digital signal processing) enables superior engineering refinement
  • LED indicators for standby and power mode
  • Cabinet

  • Vented/Ported Enclosure
  • Massive slot port with edge radius
  • Front-firing driver
  • Acoustically transparent grille
  • Super durable, black sand textured finish
  • Precision machined CNC panels
  • Rigid MDF baffles
  • Heavily braced
  • Rear mounted amplifier
  • USA manufactured rubber feet
  • Dimensions (DxWxH): 27"x24"x27" with grille
  • Weight: 150 lbs
  • Cabinet Made in the USA
  • Woofer

  • 21 inch B&C Ipal woofer design from Italy
  • 6 inch split wound aluminum voice coil
  • 5000 watt thermal capabilities
  • 99 dB sensitivity
  • Motor force of 522(BL^2 / re)
  • Extensive inductance control to optimize sound quality
  • Performance coming soon!

    Assembled with pride in Mineral Ridge, ohio
